Sirius 100 Pressure Sensitive Labeling System

The new Sirius 100 range of labeling systems are specifically designed to meet the modern demands of today’s fast-moving, highly flexible production lines. Drawing from its strong history, Accraply has transformed the technology-driven linear labelling of its high speed systems into an extremely cost effective single and twin head labelling solution.

COST-EFFECTIVE HIGH-SPEED LABELER
Single or twin-head labeling available.

SIMPLE NO-TOOL CHANGEOVERS
Minimal downtime and reduced waste means higher profit for you.

OPTIONAL NEXT GENERATION SMART INTERFACE
Preventative maintenance alerts
Video change-over assistance
On-board troubleshooting and diagnosis
On-board efficiency reporting

ACCURATE
All major axes including conveyor, stabilizer and wrap are servo-driven, providing increased accuracy and product handling flexibility.

RUGGED STAINLESS STEEL FRAME
Durable construction our customers expect from long-lasting Accraply equipment.

WORLDWIDE SUPPORT NETWORK
 Global expertise served locally: 7 days a week, 365 days a year.




  • Operator Control – Choose from on-board decentralized controls or an optional integrated full color HMI. The optional HMI carries the following standard benefits to the user:
    • Centralized control for operator ease of use
    • Full record of operator actions and password compliance
    • Product recipe management as standard
    • Operator manual stored within HMI
    • Electrical Schematics stored within HMI
    • Video tutorials stored within HMI
  • Servo Axes – The use of servo controlled motion for all major axes provides the 100 series labeler and the user with much greater flexibility on product handling options and controls. Synchronized for perfect speed matching the label application and control systems work effectively to control even the most difficult applications.
  • RCO – RAPID CHANGEOVER, Accraply recognizes the need for highly flexible highly configurable quick changeover lines. The extensive use of toolless changeover and scales make the 100 Series an extremely fast machine to configure and change.
  • Rugged stainless steel frame.
  • High-speed labeling heads.
  • Wrap labeling, Front & Back labeling.
  • Low total cost of ownership.
  • Production Rates:
    Up to 300 products per minute depending on product and label sizes.

  • Electrical Requirements:
    220V/240 V single phase AC, 50/60 Hz. Special electrical options available on request.

  • Air Requirements:
    Air required for some overprinters and security systems.

  • Weight:
    As standard 320 kg

  • Product Capacity:
    Maximum Diameter 100 mm / 3.9"
    Maximum Height: 350 mm / 13.75"
    Minimum Height: 20 mm / 0.75"
    Maximum Width: 200 mm / 7.8"
    Minimum Width: 15 mm / 0.6"

  • Label Capacity:
    Maximum Web Width: 155 mm / 6.1"
    Minimum Web Width; 13 mm / 0.5"
    Maximum Label Length: 330 mm / 13"
    Minimum Label Length: 10 mm / 0.4"
